TROUBLESHOOTING HELP REQUESTED! Please [Contact us] if you find a bad link or get an error message, etc, and send us info about what page or item you were on when you saw the issue, with a link if possible, or a screen shot. Not the error screen, we need to know where you were before the error and what you were clicking on. Thanks! ~Mo, Parts & Tech SupportPenn SSV7500 SS Series Skirted Spool Black/Gold Reel
Model Specs:
More Info- Machined gold anodized aluminum skirted spools, with handy line capacity chart.
- New thicker heavy duty aluminum bail wire adds strength and durability
- 5 Shielded stainless steel bearing system
- Infinite anti-reverse (back up ratchet on 7500-10500 sizes
- Friction trip ramp prevents premature bail trip when casting
- Stainless steel mainshaft and alloy main gear
- Triple-supported and oversized stainless steel mainshaft on 9500 and 10500 models
- Enhanced gear ratios on smaller sizes
- A full metal body and sideplate keep precise gear alignment under heavy loads.
- No backing needed because the rubber gasket keeps superline from slipping.
- * 9500 and 10500 Models available January 2013. 3500-8500 sizes available October 2012 *
- * All Live Liner models will be available January 2013 *
| Mono Cap (yds/lb) |
Braid Cap (yds/lb) |
Bearings | Max Drag | Gear Ratio | Line Retrieve |
|---|---|---|---|---|---|
| 440/15 300/20 210/30 |
430/40 360/50 320/65 |
5 + 1 | 35 | 4.7:1 | 36 |
1-SSV7500
001-1277139
001-1277139
1-SSV7500 Body Assembly (Housing) MEASURE!
READ NOTES IN DESCRIPTION BEFORE ORDERING!
$24.70
8A-SSV7500
008A-1277146☀
008A-1277146☀
8A-SSV7500 Washer, Drive Gear Shim Washer
Used on multiple models in different quantities.
$1.30
15L-SSV7500
015L-1292784
015L-1292784
15L-SSV7500 Seal, Handle Seal
Used on multiple models in different quantities.
$2.10
20A-SSV7500
020A-1277152☀
020A-1277152☀
20A-SSV7500 Bearing, Ball Bearing (Metal Sealed)
MULTI USE See Description
Used on multiple models in different quantities.
$20.80
20B-SSV7500
020B-1344681☀
020B-1344681☀
20B-SSV7500 Bearing, Ball Bearing (Plastic Sealed)
Used on multiple models in different quantities.
$11.80
22-SSV5500
022-1277046☀
022-1277046☀
22-SSV5500 Screw (Round Phillips Head)
Used on multiple models in different quantities.
$1.30
35A-SSV5500
035A-1277060☀
035A-1277060☀
35A-SSV5500 Bearing, Ball Bearing
Used on multiple models in different quantities.
$4.90
38A-SSV5500
038A-1277063☀
038A-1277063☀
38A-SSV5500 Screw (Flat Pan Head w/Phillips Cut) (Machine Thread)
MULTI USE See Description
Used on multiple models in different quantities.
$1.30
39A-SSV7500
039A-1277170☀
039A-1277170☀
$2.55
39B-SSV7500
039B-1277171★
039B-1277171★
$1.30
43A-SSV7500
043A-1277173
043A-1277173
$1.30
43B-SSV5500
043B-1277070☀
043B-1277070☀
43B-SSV5500 Screw (Round Head)
REPLACES ORIGINAL NUMBER 231G-SSV5500 ON SOME REELS
Used on multiple models in different quantities.
$1.30
43C-SSV5500
043C-1277071☀
043C-1277071☀
$1.30
44-SSV7500
044-1277174★
044-1277174★
$1.30
46-SSV7500
046-1277176☀
046-1277176☀
$1.30
56-SSV7500
056-1277185◉
056-1277185◉
$23.25
56T-SSV5500
056T-1277089◉
056T-1277089◉
$9.50
57-SSV7500
057-1277186
057-1277186
$1.85
57T-SSV7500
057T-1277187
057T-1277187
$1.85
231-SSV7500
231-1277193▲
231-1277193▲
231-SSV7500 Gear, Crosswind Gear (Oscillation Gear) - MEASURE!
READ NOTES IN DESCRIPTION BEFORE ORDERING!
$1.65
231B-SSV3500
231B-1307857☀
231B-1307857☀
231B-SSV3500 Screw, Crosswind Gear Screw (Oscillation Gear Screw) (Phillips Thin Head 1/4" Dia)
READ NOTES IN DESCRIPTION BEFORE ORDERING!
$1.30
231B-SSV5500
231B-1277100☀
231B-1277100☀
231B-SSV5500 Screw, Oscillation Gear Screw (Crosswind Gear Screw (Phillips Thin Head 5/16" Dia)
READ NOTES IN DESCRIPTION BEFORE ORDERING!
$1.30
232B-SSV7500
232B-1302503★
232B-1302503★
$1.30
